In early 2023, CheckPoint incident response team investigated an incident at a European hospital. The investigation showed that the malicious activity observed was likely not targeted but was simply collateral damage from Camaro Dragon’s self-propagating malware infections spreading via USB drives.
Camaro Dragon is a Chinese-based espionage threat actor whose operations are actively focused on Southeast Asian countries and foreign entities related to them. The threat actor shares similarities in TTPs and resources with previously reported activities conducted by Chinese threat actors, namely Mustang Panda and LuminousMoth.
As a part of the investigation and tracking the threat actor, we encountered multiple newer versions of the toolset observed in the European hospital, with similar USB-propagating capabilities that allow the malware to spread uncontrollably. These tools, which we track as WispRider and HopperTick, align with other tools by the same threat actor recently discovered by CPR, such as a Go-based backdoor called TinyNote, and a malicious router firmware implant named HorseShell. All of them share infrastructure and operational goals.
In this report, we provide a full technical analysis of the infection chains and their various components. We cover HopperTick, a malicious launcher that is propagated via USB drives, and WispRider, which serves as its main payload and facilitates the propagation. We explain the mechanism by which infections spread from the initially targeted networks to many others through infected USB drives, ultimately reaching environments far beyond the scope of the threat actor’s primary interests.
European Healthcare Institution Infection – How Did It Start
Patient Zero in the malware infection was identified as an employee who had participated in a conference in Asia. He shared his presentation with fellow attendees using his USB drive. Unfortunately, one of his colleagues had an infected computer, so his own USB drive unknowingly became infected as a result. Upon returning to his home hospital in Europe, the employee introduced the infected USB drive to the hospital’s computer systems, which led the infection to spread.
This incident provided an in-the-wild sighting of a set of tools described back in late 2022 in the Avast report (the toolset is labelled there as SSE), which analyzed several malicious tools staged on one of the distribution servers attributed to Mustang Panda. The infection chain starts when a victim launches a malicious Delphi launcher on the infected USB flash drive. The launcher reveals all of the victim’s previously hidden files and is responsible for unleashing the main backdoor and infecting each new drive it interacts with.
The Infector (Symantec.exe + LDVPOCX.OCX)
On any infected USB flash drive, all the user’s files are hidden in a separate folder, and the victim only sees the malicious launcher that bears the USB drive name and a USB drive icon. When the victim clicks on it, the launcher, written in Delphi, reveals all the user’s files that were hidden, and starts the PE pre-existing at a specific USB path Kaspersky\Usb Drive\3.0\Symantec.cmd. This is a legitimate Symantec component that side-loads the malicious LDVPOCX.OCX which is located in the same folder. After creating a mutex and handling persistence via the registry Run key, the infector copies its working files from another hidden folder on the USB drive to the infected machine. It places .dat files, which are encrypted payloads, in a folder C:\ProgramData\SymantecSEndponit\Data: EdrEpmpCStorages.dat, PchEpmpCStorages.dat, prodcltdef.dat, csdkset.dat. Two files are then decrypted and moved into C:\ProgramData\Vivaldi\Application (vivaldi.exe, vivaldi_elf.dll), and two more files are decrypted and moved into C:\Users\odin\AppData\Local\Cyber (CUZ.exe, ZIPDLL.dll)). Then both of these executables are started (vivaldi for the evasions module and CUZ for the main backdoor), causing them to side-load the malicious DLLs placed next to them.
USB infection setup
After all the files were copied, and the evasion module and the backdoor started, the infector creates two threads that are used for portable drives infection.
One thread creates a fake window that listens through a window procedure function for DBT_DEVICEARRIVAL and DBT_DEVICEREMOVECOMPLETE events. Listening to those events enables it to detect when a new USB device is inserted and to then infect it. Before starting the next thread, the infector enumerates all available drives by using the GetLogicalDriveStringsW API. It checks each drive to determine it is a hot-pluggable device by sending it an IOCTL_STORAGE_GET_HOTPLUG_INFO request, using the IO control code 0x2D0C14u. Then, if the device is hot-pluggable, it internally marks this drive letter, thereby indicating for the soon-to-be-created created thread that this drive should be infected.
The second thread then reviews all of the drive letters. Any marked drives will be infected (described in the next section). From this moment, any USB drive that is connected to the system will be infected. It is interesting to note that existing network drives are not infected, but network drives that are added post-infection will be infected as well. This behavior is due to the lack of “hot-pluggable” checks in the window procedure created by the first thread; it infects any new device that is added and triggers one of the listened to event codes. Although network drives infected this way theoretically might be used as a means of lateral movement inside the same network, this behavior appears to be more of a flaw than an intentional feature. Manipulating numerous files and replacing them with an executable with a USB thumb drive icon on network drives is a conspicuous activity that can draw additional, unfavorable attention.
When a benign USB thumb drive is inserted into an infected computer, the malware detects a new device inserted into the PC and manipulates its files, creating several hidden folders at the root of the thumb drive:
Kaspersky\Usb Drive – All files that existed on the thumb drive prior to the infection are moved to this folder.
Kaspersky\Usb Drive\3.0 – All .dat files from C:\ProgramData\SymantecSEndponit\Data\, LDVPOCX.OCX (Infector DLL) and Symantec.cmd (legitimate Symantec executable which side-loads LDVPOCX.OCX) are moved here.
Finally, the malware copies into the thumb drive a Delphi loader with the name of the original thumb drive name, with a USB thumb drive icon:
There is no special technique used in this USB infection flow to automatically run the Delphi launcher. The scheme fully relies on social engineering; the victims can no longer see their files on the drive and are left only with the executable, which they will likely click to reveal their files – thereby setting off an infection flow of the machine.
The Backdoor (CUZ.exe/msexpert.exe + ZIPDLL.dll)
ZIPDLL.dll is the main backdoor side-loaded by CUZ.exe, a component of CAM UnZip software. The backdoor has 3 stages, each receiving a different set of arguments.
Setup. The malware gets as an argument the path where it should be copied together with ZIPDLL.dll. This is the exact command that the infector uses to execute it: C:\Users\user\AppData\Local\Cyber\CUZ.exe "C:/Users/user/AppData/Local/MicrosoftExplorer/msexpert.exe". In addition to setting up the “worker” copy, it also decrypts the shellcode embedded inside, generates a random key, encrypts the shellcode, and writes it to the file c:\users\public\winmine.bin. If the malware runs without an argument, it opens a once popular Minesweeper game (winmine.exe).
Anti-analysis. The malware uses an interesting technique, recursively producing a process tree before continuing the execution. It starts the worker (msexpert.exe) with two arguments: a number (100) and the string of ASCII characters, which is the key that decrypts the shellcode stored in the winmine.bin file. After startup, the worker executes itself again recursively, with the first argument decreasing by 1 on each iteration. The behavior continues until the number goes down to zero, and then the worker is finally executed only with the encryption key.
Execution. When the msexpert.exe process is executed with a key as an argument, it decrypts the shellcode from winmine.bin and patches the executable in the memory to execute the shellcode. Next, the ZIPDLL.dll and the winmine.bin files are removed from the disk.
The backdoor has limited capabilities which it can execute according to the following commands from the C&C server:
Delete the specified file.
Create a file and write to it.
Create the process.
Evasions module (vivaldi.exe + vivaldi_elf.dll)
The evasion module is vivaldi_elf.dll, which is side-loaded by a legitimate component of the Vivaldi browser. It is mainly responsible for changing the registry keys under SOFTWARE\\Microsoft\\Windows\\CurrentVersion\\Explorer\\Advanced\\ such as Hidden ,HideFileExt and ShowSuperHidden. All of those are related to hidden file attributes in the system.
The Vivaldi executable shows the same behavior as msexpert.exe, running with an argument (100) to launch itself recursively with decreasing arguments until it reaches 0.
When searching for similar files in the wild, we found numerous newer versions circulating worldwide, most of which also first originated from Southeast Asia. While preserving the same capability to self-propagate via USB drives, these samples have a few significant technical differences from the case we observed at the European hospital:
Instead of a “modular” structure, where each component is represented by a separate set of legitimate executables and side-loaded DLLs, all the functionality (USB infector, evasions module, and the backdoor itself) is combined inside the same payload.
For DLL-side-loading of the payloads, the actors use some legitimate executables not discussed previously, such as components of GDATA Total Security Solution, Electronic Arts Games Access Server, or the RiotClient UX component. The malware versions also require a proper argument to be provided to the legitimate executable for the side-loaded DLL to reveal its malicious capabilities.
The code of the malware components has undergone significant refactoring, heavily utilizing the capabilities of the C++ language. This applies to all the components, including the USB launcher, which was previously written in Delphi.
One of the USB launchers for the updated payload versions was submitted multiple times to VT in the last half year, with a clear geolocation cluster moving from Myanmar to Russia in the later stages of this malware’s proliferation.
This specific USB launcher was also digitally signed with a known malicious signature by 北京弘道长兴国际贸易有限公司 (Beijing Hongdao Changxing International Trade Co., Ltd.), the certificate was explicitly revoked some time ago.
Similar to the previous versions, the infection chain starts when a victim plugs in a compromised USB device and executes a malicious launcher from its root directory. We further track the updated USB launcher as HopperTick and the unified backdoor-infector component as WispRider.
HopperTick (USB launcher) analysis
HopperTick is an MFC application whose purpose is to pass an infection from an infected USB thumb drive. The launcher is saved on the USB thumb drive, with the thumb drive current name and a USB thumb drive icon. Those steps are part of a social engineering scheme to get an unsuspecting user to click and execute the launcher. Upon execution, HopperTick determines the drive letter of the USB thumb drive from which it’s running by calling the GetModuleFileNameW function and then manipulating the received module file name. Next, it generates an ID for the thumb drive based on the volume serial number received from the GetVolumeInformationW API. Then, combining all of the gathered information, it creates the following string: [DRIVE_LETTER]:\\Kaspersky\\Usb Drive\\3.0\\[DRIVE_ID] and checks if the file exists. If it doesn’t, the launcher also tries to look in the file path [DRIVE_LETTER]:\\System Volume Information\\[DRIVE_ID].
The file [DRIVE_ID] contains a shellcode that is loaded, decrypted, reallocated, and executed in memory using VirtualProtect. The application itself doesn’t continue its own execution but jumps directly to the shellcode and continues executing from it.
The execution flow consists of several steps:
Closes the File Explorer window where the victim originally started the launcher. The shellcode does this by calling the function GetForegroundWindow and then PostMessageW with the WM_CLOSE message.
Bypasses SmadAV. SmadAV is a “second-layer antivirus” that is popular in Southeast Asian countries. The bypass is done exactly the same way as in Camaro Dragon’s TinyNote backdoor which we reported on recently.
Checks if the USB device is media-removable and hot-pluggable, by sending an IOCTL request to the thumb drive with the IoControlCode IOCTL_STORAGE_GET_HOTPLUG_INFO and checking for relevant features in the received STORAGE_HOTPLUG_INFO struct.
Creates a new Explorer process and opens a folder on the USB thumb drive containing the user’s original files (in most cases we observed). The path is similar across all versions: [DRIVE_LETTER]:\\Kaspersky\\Usb Drive\\.
Infects the machine: Creates a working folder inside C:\\ProgramData\\, decrypts the .data files located in [DRIVE_LETTER]:\\Kaspersky\\Usb Drive\\3.0\\ folder and saves them to the disk. These files include a legitimate executable, a fake DLL that is side-loaded by the executable, and a binary file containing both the configuration and encrypted payloads. Below is the list of the legitimate executables used for side-loading in this campaign:
KidSafe (part of GDATA Total Security), G DATA Software AG
When side-loaded by the legitimate executable, the DLL first checks if the executable was executed with a specific hardcoded number as an argument. If the argument check fails, the process exits as a means of an anti-sandbox technique which does not allow the malware to reveal its capabilities when running dynamically without a proper infection chain.
Sets up persistence by adding the Run registry key and scheduled task with the path to the legitimate executable and the proper argument (e.g. "C:\ProgramData\EACoreService\EACoreServer.exe" 114).
WispRider (infector and backdoor) analysis
WispRider is a side-loaded DLL which contains both the USB infector component and the backdoor itself. It first creates a mutex to ensure there is a single instance running and checks that the executable that side-loaded it was executed with the proper argument. Next, it searches for a configuration file by first identifying a currently running directory from which the executable runs, and then recursively scanning from that directory to check each file as a potential config file candidate. A valid config file can be represented in the following struct:
For each file encountered during the config search process, the malware first checks the CRC32 checksum by comparing the first 4 bytes with the CRC32 checksum of the rest of the file. If this check goes through, a path to a valid config file is saved, and WispRider proceeds to decrypt the config file using simple XOR encryption loops, starting with the first key (key_1) and then again using XOR with the second key (key_2).
The config file contains relevant paths where the files should be stored both on an infected PC or an infected USB drive, and the actual encrypted content of these files. The data stored in the config file can be represented in the following struct:
After the config is fully loaded and parsed, WispRider checks from which process it runs, and then compares it to each file path from config_data_entry with the type field equal to 1 (EXE). This allows the sample to understand if it’s running from an already infected machine or if the machine needs to be infected. This determines its next behavior. If the malware discovers that it is running from an already infected computer, it goes over the list of config entries and looks for files with the mode field set to 2, indicating additional payloads, copies them to the PC, and executes them. In our case, one of the files had a reference to HPCustParticUI.exe, a legitimate executable that side-loads HPCustPartUI.dll, a “Disk Monitor” tool which is a version of a stealer discussed by Avast in the overview of the threat actor’s tools.
If the sample is not run from an infected machine, it continues to infect the present machine. This is likely an alternative infection vector that delivers the malware to the targeted network when the actors cannot rely on the USB propagation, as they can’t physically access the machine to plug in an infected drive. Based on the known TTPs of the threat actor, we might suggest that these infections are initiated via spear-phishing campaigns that deliver an archive with all the infection-related files and assure the legitimate executable runs with a relevant argument.
To infect the machine, the malware goes over the list of files from the configuration that are intended for the PC (mode=1). For each one, it creates the needed directories and then copies the files over. For example, in the case EACoreServer.exe is used, it first creates the directory tree C:\ProgramData\EACoreService\ and then copies two files into it: EACoreServer.exe and EACore.dll.
After copying all the files, the malware creates in its working folder a newly re-encrypted config file. Its structure and the data are the same, but both encryption keys (and their sizes) are different. For new encryption keys, the sample uses two arrays filled with random values and randomizes 2 parameters for each of the keys: the key size, and what index in the relevant array the key starts from. Next, it takes the relevant bytes from pre-generated arrays, encrypts with them the config data, performs CRC32 checksum on the config data to write it at the beginning of the config file, and saves everything to the working directory with .dat name matching the side-loaded DLL (such as EACore.dat).
After setting up all the files, WispRider establishes persistence for the file that has the field type set to 1, e.g. for the legitimate executable. It does something similar to the HopperTick, by adding both a registry Run key and a scheduled task pointing to the executable with the relevant argument.
Finally, regardless of whether WispRider had to infect the machine or was running initially from the infected machine, it creates two threads: one is responsible for communication with the C&C server, and another one infects any existing or newly connected USB devices.
Upon execution, the USB infection thread loads the configuration file again and saves it internally to a shared struct. Then the thread creates a fake window, with a random 16-character class name and window names. It then registers a WndProc function, which listens for any WM_DEVICECHANGE message types which are sent on various event types, but most importantly, when the USB device is connected to the system.
The infection process of each USB device consists of a few stages:
Create a struct per USB device: The malware determines the drive letter, and then creates the following struct for it:
Cleanup: The malware first goes over the newly attached USB drives and deletes any file of the following types on it: .exe, .lnk, .scr, .com, .vbs, .hta.
Create a whitelist: The malware creates a whitelist of all files that are related to the USB infection (with mode=0) from the previously loaded config. This whitelist is used whenever any file operations occur on the USB and makes sure the infection files stay intact regardless of what manipulations are performed on the USB.
Monitor a device: Each infected USB has its dedicated thread which runs in a loop as long as the device is attached. This loop performs the following actions:
At the start of the loop, there are several writes to the following registry keys to help with hiding the victim’s files on both the USB and on the infected machine. In previous versions, this functionality was a part of the vivaldi module:
A few checks to validate if the USB device needs to be infected. If any of the conditions below are met, the USB device is infected:
No config on the USB device.
Failure to decrypt the config file already existing on the USB device.
Partial or corrupted config file.
Partial infection occurred or infection-related files are missing.
The malware also knows to update itself to the newer version. If the version of the config already existing on the USB is lower than the config from the sample, the malware performs the infection update.
If the USB is determined to be infected, all files that existed on the USB device, except the previously created whitelist, are moved to the folder Kaspersky\Usb Drive. Next, the files from the config with mode=0 are moved to the folder Kaspersky\Usb Drive\\3.0 with their corresponding name in the config. The config itself is re-encrypted as described previously and placed in the same folder. Finally, the malicious launcher is placed at the root of the USB, with the name of the character of the USB device, and a USB drive icon so it can impersonate a USB device. This is a social engineering trick to get unsuspecting or negligent users to execute the malware.
If the USB infection flow worked as expected, the following struct is created:
This struct is updated in a global array of such structs, where the index in the array is the USB drive character. This struct holds a newly created event, a new thread created per the attached device, a file handle to the USB device itself, and the USB drive path.
The newly created thread monitors any file changes on the USB thumb itself: when a new file is created, it is moved immediately to the folder with all of the other user files.
The calling thread also keeps monitoring the USB. In case there are any changes to the infection-related files, it overwrites them to make sure the USB can carry the infections further.
C&C Communication and backdoor capabilities
Upon execution, the thread first resolves more API calls and generates a bot id based on available data about the infected machine from various functions such as NetBios and GetVolumeInformationA. Next, it proceeds to set up the C&C-related parameters based on a hexadecimal representation of an IPv4 and port:
At first, it seems odd to see that this version uses the local computer IP address. Upon further investigation, it turns out that another function is using the domain www.beautyporntube[.]com to resolve the second C&C server address and overwrites the entries containing local IP 127.0.0.1 with an IP it resolves from the previously mentioned domain.
Communication with the C&C server occurs through raw sockets, and the traffic itself is encrypted using XOR encryption, where the key is randomly generated and present at the beginning of the request. The generated key is also used to decrypt the incoming response from the C&C server. First, the malware sends a request containing the infected computer name, with message_id equal to 5. If there is any response from the C&C server after sending this message, the malware sends another request, this time as the message_id=4 with random data. This request signals to the C&C server that the malware is waiting to receive a command.
These are supported commands:
Execute a command by creating a named pipe to cmd.exe, then read the input from the pipe and send it back to the C&C server
Read from the previously created named pipe and send the information back.
Open a file for reading or writing.
5 / 6
Write to file.
Close the file handle to the previously opened file.
Judging by the available C&C commands, the backdoor capabilities are limited in this version. Similar to the previous version, the backdoor is used to gain a foothold in the infected environment and run additional payloads from the C&C server.
Post-exploitation tools: Disk Monitor
As we mentioned earlier, one of the payloads delivered together with WispRide is HPCustPartUI.dll, a DLL which is side-loaded by HPCustParticUI.exe. Its purpose is to scan all the drives of the infected system for files with predefined extensions and stage them for exfiltration.
The DLL requires a configuration file called HPCustPartUI.log located in the same folder. The config is encrypted using XOR with the key DKJfeoirj39 and contains the path to stage the files and a list of the extensions to be monitored (in our case these values are hardcoded: .docx, mp3, wav, m4a, wma, aac, cda, mid).
When a new file with a monitored extension is created, it is copied to the location specified in the config with the name format <timestamp>_<original_file_name>.<extension>, which preserves the folder structure of each copied file. In parallel, the Disk Monitor tool also notifies its C&C server on each of these files, sending the message in the following format:
<machine name> <machine id> <path to the file of interest>
The data in the request is XORed with the key “DMkeir” and sent to the C&C server via HTTPS with User-Agent “Mozilla/5.0”.
As for the exfiltration component, although we didn’t observe it this time, the actors were previously seen using for exfiltration their own FTP servers along with the usage of third-party services such as Google Drive.
The Camaro Dragon APT group continues to employ USB devices as a method for infecting targeted systems, effectively combining this technique with other established tactics. These include DLL side-loading by exploiting security solution components, bypassing the SmadAV antivirus solution which is popular in Southeast Asian countries, and disguising malware folders as legitimate security vendor files. The consequences of a successful infection are twofold: the malware not only establishes a backdoor on the compromised machine but also spreads itself to newly connected removable drives.
The ability to propagate autonomously and uncontrollably across multiple devices enhances this threat’s reach and potential impact. This approach not only enables the infiltration of potentially isolated systems but also grants and maintains access to a vast array of entities, even those that are not primarily targeted.
